| For Cold Heading
DSR's Stainless Steel Wire for Cold Heading is made by special heat treatment following selection of wire rod. This enables customers to obtain products of excellent surface and metal structure necessary for superior products in spite of severe pressure condition. DSR is able to manufacture the products by lightly drafted.
| |
| |
| ● Type |
| Type |
Grade |
Symbol |
Dia(mm) |
Surface Finish |
| Austenite |
AISI 304 |
WSA |
0.8 ~ 10.0 |
Bright & S-Co |
| AISI 302HQ (XM-7) |
| AISI 316 |
| AISI 305 |
| AISI 304J3 |
| AISI 302HQ (XM-7) |
WSB |
0.8 ~ 20.0 |
| AISI 304J3 |
| Ferrite |
AISI 430 |
WSB |
0.8 ~ 20.0 |
| Martensite |
AISI 410 |
WSB |
0.8 ~ 20.0 | |
| |
| ● Tolerance & Ovality of Diamater & Allowance range of Pit depth |
| Dia (mm) |
Tolerance (mm) |
Ovality (mm) |
Allowance of Pit depth |
| 0.80-3.00 |
+0 |
0.013 |
0.02 under |
| -0.025 |
| 3.01-6.00 |
+0 |
0.015 |
0.03 under |
| -0.03 |
| 6.01-10.00 |
+0 |
0.020 |
0.05 under |
| -0.04 |
| 10.01-20.00 |
+0 |
0.025 |
0.06 under |
| -0.05 | |
| |
| ● Mechanical Properties |
| Symbol |
Grade |
Dia |
Tensile Strength |
Elongation |
Reduction of |
| (mm) |
(N/mm2) |
(%) |
(%) |
| WSA |
AISI 302HQ (XM-7) |
2.00 under |
480 ~ 630 |
30 over |
70 over |
| 2.00 over |
440 ~ 590 |
40 over |
| AISI 304HC |
2.00 under |
560 ~ 710 |
30 over |
70 over |
| 2.00 over |
510 ~ 660 |
40 이상 |
| AISI 304 |
2.00 under |
560 ~ 710 |
30 over |
70 over |
| 2.00 over |
510 ~ 660 |
40 over |
| AISI 316 |
2.00 under |
560 ~ 710 |
30 over |
70 over |
| 2.00 over |
510 ~ 660 |
40 이상 |
| AISI 305 |
2.00 under |
530 ~ 680 |
30 over |
70 over |
| 2.00 over |
490 ~ 640 |
40 over |
| WSB |
AISI 302HQ (XM-7) |
2.00 under |
500 ~ 680 |
20 over |
65 over |
| 2.00 over |
450 ~ 630 |
25 over |
| AISI 304HC |
2.00 under |
580 ~ 760 |
20 over |
65 over |
| 2.00 over |
530 ~ 710 |
25 over |
| AISI 304 |
2.00 under |
580 ~ 760 |
20 over |
65 over |
| 2.00 over |
530 ~ 710 |
25 over |
| AISI 316 |
2.00 under |
580 ~ 760 |
20 over |
65 over |
| 2.00 over |
530 ~ 710 |
25 over |
| AISI 305 |
2.00 under |
560 ~ 740 |
20 over |
65 over |
| 2.00 over |
510 ~ 690 |
25 over |
| AISI 430, 410 |
2.00 under |
500 ~ 700 |
10 over |
65 over |
| 2.00 over |
450 ~ 600 |
10 over | |
| |
| |
 |
| |
| ● Packing |
| Dia(mm) |
Coil Dia(Inch) |
WSA |
| Unit Weight(kg) |
| Coil |
Carrier |
Pay-off Drum |
| 0.80 ∼ 1.80 |
16 |
60 |
200 |
200 |
| 1.81 ∼ 2.90 |
24 |
80 |
300 |
- |
| 2.91 ∼ 6.00 |
24 |
100 |
600 |
|
| 6.01 ∼ 10.00 |
28~30 |
600 |
1000 |
- |
| Dia(mm) |
Coil Dia(Inch) |
WSB |
| Unit Weight(kg) |
| Coil |
Carrier |
| 0.80 ∼ 1.80 |
16 |
50 |
- |
| 1.81 ∼ 2.90 |
24 |
100 |
300 |
| 2.91 ∼ 6.00 |
24 |
250 |
600 |
| 4.50 ∼ 8.00 |
28 |
500 |
900 | |
